Intelligent multi-head metering pump series
Home > Product center > Intelligent multi-head metering pump series
Product center > Intelligent multi-head metering pump series
Double head intelligent metering pump series
l Compact structure, small size, high precision, corrosion resistance and high temperature resistance.
l The 2 heads are easy to disassemble and install and can be cleaned online by switching the valve to the forward and reverse directions.
l It can be sterilized by negative pressure, high temperature and steam.
l Precision wire motor drive, high performance, long service life, high strength and repeatable operation.
l Digital touch screen mediates measurement capacity.
l No quick-wear parts, zero maintenance and repair costs.
l Anti-chemical reaction prevention is compatible with most fluids.
Telephone：0769-83328418
Message feedbackDetailed introduction
Widely used for:Precise quantity filling of liquids such as biological agents, pharmaceuticals, batteries, CVs, heat pipes, liquid agents, perfumes, etc.
Product performance:
l Compact structure, small size, high precision, corrosion resistance and high temperature resistance.
l The 2 heads are easy to disassemble and install and can be cleaned online by switching the valve to the forward and reverse directions.
l It can be sterilized by negative pressure, high temperature and steam.
l Precision wire motor drive, high performance, long service life, high strength and repeatable operation.
l Digital touch screen mediates measurement capacity.
l No quick-wear parts, zero maintenance and repair costs.
l Anti-chemical reaction prevention is compatible with most fluids.
Technical Parameters
Specification & Model | JKR-ZNX2-M500μl | JKR-ZNX2-M1500μl | JKR-ZNX2-M3500μl | JKR-ZNX2-M6500μl | JKR-ZNX2-M10ml |
Plunger material | Alumina / zirconia / silicon nitride / sapphire (optional) | ||||
Valve direction switching | Stepper motor | ||||
Driving mode | Precision screw motor / servo (optional) | ||||
Stroke speed | 1-200r / min (preparation and selection) | ||||
Adjustment mode | Digital screen touch screen smart adjustment | ||||
No. of pump heads | 2 | ||||
Single stroke range | 3-500μL | 5-1500μL | 20-3500μL | 50-6500μL | 0.1-10ml |
Stroke accuracy | ±0.3‰ | ±0.4‰ | ±5‰ | ±5‰ | ±5‰ |
Liquid inlet pipe | Φ2.5×4mm | Φ4×6mm | Φ6×8mm | Φ6×8mm | Φ6×8mm |
Outlet pipe | Φ1.0×1.6mm | Φ2.5×4mm | Φ4×6mm | Φ4×6mm | Φ4×6mm |
Communication interface | RS23 2(485 optional), I/O, CC TRIG, AUX OUT | ||||
Power supply | 220V/50HZA or 120V/60HZ (optional) | ||||
Work environment | Use temperature and humidity 5-40℃, below 85%RH | ||||
